Building Charts with Pure CSS — No SVG, No Canvas, No JS Required

Most developers reach for a chart library the moment they need a visualization — Chart.js, Recharts, D3 — and suddenly their page is carrying a hefty bundle just to draw a few lines. What if CSS alone could handle it?

That's exactly what st-core.fscss pulls off. It renders fully functional line charts using nothing but browser-native CSS features, compiled at build time.

The Mechanism Behind It

Three CSS primitives do all the heavy lifting:

• clip-path: polygon() — shapes each line visually
• CSS custom properties (--st-p1 through --st-p8) — hold the data points
• FSCSS mixins — generate the chart structure during compilation

The data pipeline looks like this:

data → CSS variables → clip-path → rendered chart

Everything is resolved before the browser even touches it. No runtime rendering, no extra DOM depth, no JavaScript dependency for visuals.

Rendering Multiple Lines

The multi-line chart is a great showcase of how elegantly this scales. The approach uses one shared renderer with per-element data overrides — each line element carries its own dataset via scoped CSS variables.

<script src="https://cdn.jsdelivr.net/npm/fscss@1.1.24/exec.min.js" async></script>

<style>
@import((*) from st-core)

@st-root()

.chart {
  height: 200px;
  position: relative;
  @st-chart-points(20, 25, 21, 37, 30, 60, 27, 50)
}

@st-chart-line(.chart-line)

.chart-line {
  background: currentColor;
  @st-chart-line-width(2px);
}

.line-1 { color: #32D8D4; }

.line-2 {
  color: #E8A030;
  @st-chart-points(10, 20, 16, 15, 66, 50, 80, 54)
}

.line-3 {
  color: #B840C8;
  @st-chart-points(5, 39, 20, 30, 27, 70, 60, 70)
}

@st-chart-grid(.chart-grid, 10, 7)
@st-chart-axis-y(.y-axis)
@st-chart-axis-x(.x-axis)
</style>

<div class="chart">
  <div class="chart-line line-1"></div>
  <div class="chart-line line-2"></div>
  <div class="chart-line line-3"></div>
  <div class="chart-grid"></div>
  <div class="y-axis">
    <span>0</span><span>20</span><span>40</span>
    <span>60</span><span>80</span><span>100</span>
  </div>
</div>

<div class="x-axis">
  <span>Sun</span><span>Mon</span><span>Tue</span>
  <span>Wed</span><span>Thu</span><span>Fri</span><span>Sat</span>
</div>

Each .line-* element overrides the default dataset from .chart. The renderer picks up whichever --st-p* variables are in scope for that element. Clean, composable, predictable.

Available Mixins at a Glance

All of these compile down to plain CSS — nothing ships to the browser that wasn't already resolved.

Handling Dynamic Data

For use cases where data changes at runtime, you can push updated values directly from JavaScript:

chart.style.cssText = `
  --st-p1: 40%;
  --st-p2: 75%;
  --st-p3: 60%;
`;

JavaScript passes the values; CSS renders the result. Transitions work as expected if you've defined them — no additional wiring needed.

Why This Approach Stands Out

• Zero runtime overhead — charts are compiled into static CSS, not computed on each render
• No third-party bundle — the browser's rendering engine does the visual work natively
• Plain custom properties — data lives in CSS, not buried inside a config object or framework component
• Full stylistic control — nothing is locked into a preset theme or opinionated design system

Try It

Live demo: fscss-ttr.github.io/st-core.fscss/multi-chart

Source: github.com/fscss-ttr/st-core.fscss

It's a refreshingly minimal take on data visualization — no installs, no configuration overhead, just CSS doing what it was always capable of.
